Read MorePrimary Reforming Catalyst
BR Reform 402/403 catalyst is suitable for the steam reforming process of hydrogen, methanol syngas, ammonia syngas from LPG, various refinery dry gases, natural gas, etc. BR Reform 402 is loaded in the upper part of the reformer, BR Reform 403 in the lower part of the reformer, and both of them are loaded in the ratio of 1:1 in general.
Characteristic:
BR Reform 402/403 catalysts are characterized by large surface, Low bulk density, good heat transfer, high activity, low pressure drop and high operational flexibility.
| Technical Data Sheet | |||
| Items | BR Reform 402 | BR Reform 403 | |
| Shape | 4-Hole-Cylinder, Light Black | 4-Hole-Cylinder,Gray-green | |
| Size(mm)
|
Length | 8～10 | 15～17 |
| Outer diameter | 16～16.5 | 16～16.5 | |
| Inner Diameter × Holes | 4×4 | 4×4 | |
| Bulk density(kg/l) | 0.95～1.10 | 0.90～1.05 | |
| Crush strength(N/granule) | ≥200 | ≥300 | |
| Active component (%) | NiO≥15 | NiO≥10 | |
| Promoter %(wt) | K2O≥2 | / | |
| Loading position | Upper part of the reformer | Lower part of the reformer | |
| Loading method | sacking | sacking | |
| Operating pressure | Room pressure～5.0 | Room pressure～5.0 | |
| Operating temperature( °C) | 450～750 | 700～950 | |
| Carbon Space Velocity(h-1) | 500～2000 | 500～2000 | |
